Duct Temperature Sensor TLD2
Supplied by:
National Fire Fighting Manufacturing Company
Product Description
- TLD2 Duct temperature sensor with KP10 measuring system, thermowell for measuring element is 200 mm long, duct installation depth is 180 mm
Technical Data
- Measuring element: Active measuring element KP10Output: 2.731 V at 0 °C, TC = 10 mV/K.
- Time constant: T = 35 s at 2 m/s air velocity
- Measuring tolerance: Typically ±0.2K
- Measuring range: Minimum temperature = -40 C/Maximum temperature = +120 C
- Connection: Screw terminals, max. 1.5mm²
Specifications
| Manufacturer: | Kieback & Peter |
| Country of origin: | Germany |
| Ambient Temperature | -40C to +80°C |
| IP | 65 |
| Nominal Voltage | AC 24V ± 10 %, 0.5VA |
| Ambient Humidity | 0 to 90% r.h. |
| Function | Temperature Voltage Transmitter |
